XLPE Insulated Cable

MOQ: 100 metrów
Cena £: USD 1.55-2.88/M
standardowe opakowanie: Drewniany bęben
Okres dostawy: 7 dni
metoda płatności: L/C, T/T
Pojemność dostaw: 836974 km / tydzień
Szczegóły Informacje
Opis produktu
Szczegółowe informacje
Miejsce pochodzenia
CHINY
Nazwa handlowa
QINGDAO YICABLE CABLE
Orzecznictwo
KEMA/CE/ISO/TUV/RoSH
Konduktor:
Stranded Copper
Izolacja:
XLPE
Kurtka:
PVC
Próbki:
Dostępne
Napięcie testowe:
3,5 kV
Temp. Pracy:
90 stopni
Znak kabla:
Drukowanie lub wytłaczanie
Kolor kurtki:
Czarny
Podkreślić:

xlpe electrical cable

,

cross linked polyethylene cable

Opis produktu

China Good Quality CU/XLPE/PVC-0.6/1KV 3x120+2x70mm2 XLPE Insulated Power Cable



Description:



0.6/1kv XLPE Insulated Electric Power cable

CU/XLPE/PVC, IEC 60502

IEC 60502, IEC 60228, GB/T 12706.1-2008.

CE, CCC, KEMA. ISO. VDE



Constructions



Conductor : Compact stranded copper conductor, Cl.2 as per IEC 60228

Insulation : XLPE(cross-linked polyethylene) rated at 90 ℃

Sheath : PVC type ST2 to IEC 60502, black



Applications



For laying indoors and outdoors. Able to bear certain traction during installation, but not external mechanical forces. Laying single core cable in magnetic ducts is not allowed.



Standards



International: IEC 60502, IEC 60228

China: GB/T 12706.1-2008

Other standards such as BS,DIN and ICEA upon request



Technical data



Rated voltage: 0.6/1kV

Max. Conductor Temp.: normal (90℃), short circuit no more than 5 s (160℃ when section-area below 300mm2, 140℃ when section-area above 300mm2)

Min. Ambient Temp.:The cable shall be pre heated if the ambient temperature is below 0℃

Min. Bending Radius: single core cable 20(d+D)±5%

Multi-core cable 15(d+D)±5%



Certificates



CE, RoHS, CCC, KEMA and more others at request



Ordering Advice



Rated Voltage

Application Standard: IEC/BS/UL/GB

Number of Cores

Conductor Size & Construction

Type of Insulation

Armored or unarmored. If armor, the armor type & material

The Requirement of Sheath

Length of Cable & Packing Requirement

Other Requirement



Technical Specifications:



Nom. Cross-section of conductor Insulation Thickness Sheath Thickness Approx. O.D.

Approx.

Weight

 Max. D.C Resistance of Conductor (20 ℃) Testing Voltage A.C Current Rating
mm2 mm mm (mm) kg/km Ω /km kV/5min In air (A) In soil(A)
4 × 10+ 1 × 6 0.7 1.8 18.3 649 1.83 3.5 60 77
4 × 16+ 1 × 10 0.7 1.8 21.1 965 1.15 3.5 83 105
4 × 25+ 1 × 16 0.9 1.8 24..5 1456 0.727 3.5 105 125
4 × 35+ 1 × 16 0.9 1.8 26.9 1863 0.524 3.5 125 155
4 × 50+ 1 × 25 1.0 1.9 28.8 2633 0.387 3.5 160 185
4 × 70+ 1 × 35 1.1 2.0 32.4 3565 0.268 3.5 200 225
4 × 95+ 1 × 50 1.1 2.1 35.6 4735 0.193 3.5 245 270
4 × 120+ 1 × 70 1.2 2.3 41.1 5977 0.153 3.5 285 310
4 × 150+ 1 × 70 1.4 2.4 43.6 7276 0.124 3.5 325 345
4 × 185+ 1 × 95 1.6 2.5 49.1 9055 0.0991 3.5 375 390
4 × 240+ 1 × 120 1.7 2.7 54.2 11567 0.0754 3.5 440 450
4 × 300+ 1 × 150 1.8 3.1 66.3 14321 0.0601 3.5 505 515
